Food & Beverage, Pharmaceutical, Cryogenics, Chemical & Petrochemical Industries, Conventional & Nuclear Power Plants, Pumps, Hydro-Cleaning Machines, Presses, Engine Compressors, Turbines, Diesel Engines & Refrigerating Plants.

Specifications :

Standard Version: 100mm, 150mm

	Accuracy	: ±1.0% of F.S.
	Ambient temperature	: - 20°C to + 65°C
	Process temperature	: Max. 100°C
	Electric Wiring	: Junction Box
	Contact Setting	: Over on arc of 270° through a knob placed on front of lens
	Operating pressure	: 75% of the Scale Value
	Over pressure limit	: Not Suitable

	Case	: AISI 304 SS
	Ring	: AISI 304 SS, Bayonet Type
	Bourdon	: AISI 316LSS
	Socket	: AISI 316L SS (Directly Welded to Case)
	Movement	: AISI 304 SS
	Joints	: Tig Argon Arc Welding

	Protection	: IP 65
	Dial	: Aluminium, black graduation on white background
	Pointer	: Aluminium, black coloured micrometer zero adjustable
	Window	: Polycarbonate Dome
	Contact	: Silver-Nickel
	Blow off Disc	: Neoprene
	Gasket	: Neoprene

Filled Version (Option ZZ)

	Accuracy	: ±1.6% of F.S.
	Ambient Temperature	: Maximum 65°C
	Process Temperature	: + 15°C/65°C
	Window	: Acrylic
	Dampening Liquids	: Dielectric Oil
	Other Features	: Refer Specification of Standard Version

Dry But Fillable Version

	Option Code	: Fillable Dampening Liquid
	ZY	: Fillable Dielectric Oil
