Special Features : |
 |
Apply high stability and patented technology platinum RTD sensor |
|
Uses proprietary technology "balanced structure package", medium temperature self-compensation. |
|
Proprietary algorithms; can achieve high linearity, high repeatability,
high precision. |
|
Range ratio 1000:1, also can be expanded according to user requirements. |
|
Enables measurement of small flow large diameter,minimum flow rate can be measured as low as zero, resolution0.001m/s. |
|
No moving parts, vibration can be neglected. |
|
Straight pipe less demanding 1-2D |
|
Unrelated with the medium temperature and pressure. |
|
Proprietary high-temperature method, medium temperature up to +510 . |
|
Humidity algorithm used to achieve high precision measurement |
|
Flow signal enter 12-point dynamic correction, built-in 10-point amendment. |
|
Dynamic on-line correction current / voltage output. |
|
On-line continous flow,easy handling and maintenance |
|
 |
Specifications : |
|
Measuring range |
: |
0-120Nm/s (20C,101.33Kpa) |
|
Accuracy |
: |
± 0.1% of reading ± 0.5% full scale |
|
Range ratio |
: |
usually 100:1 (depending on the calibration of flow range) |
|
Diameter range |
: |
6000mm |
|
Application scope |
: |
suitable for all types of single or mixed gases,
containing dust, sand, moisture and various corrosive gases. |
|
Environmental
temperature range |
: |
-40 - +85 (no display); -30 - +70 (showing); humidity
is less than 90% RH. |
|
Medium temperature range |
: |
-40 - +100; -40 - +200; -40 - +450; -40 - +510 |
|
Sensor Material |
: |
316 stainless steel, Hastelloy, Titanium |
|
Probe rod
material (protection cover) |
: |
316 stainless steel (standard), Hastelloy |
|
Analog Output |
: |
Flow:4-20mADC,temperature:4-20mADC,maximum
load:10000 |
|
Communication |
: |
Serial output RS232/RS485 |
|
Power supply |
: |
24VDC/600mA |
|
Alarm |
: |
1-2-way relay output, 5A/220V, 5A/30VDC, type settings |
|
Large-screen LCD Display |
: |
7 instantaneous flow, 8 cumulative flow rate |
|
Process Pressure |
: |
1.6Mpa (maximum 20MPa) |
|
Installation Process Type |
|
Plug-in (card sets, card sets + ball valve, flange
connection), pipeline type (flange, screw connection) |
|
Protection class |
: |
IP66 |
|
|
|
|
